一、120*120*38
■ General Specifications
Material：Frame and Impeller:Plastic(UL94V-0)
Lead Wire：UL Type (+):Red (-):Black
Bearing Type：Sleeve Bearing & Ball Bearing
Operation Temperature：-10℃～70℃ 35%-85%RH
Storage Temperature：-40℃～80℃ 35%-85%RH
产品规格：
| 型号列表 | 额定电压 | 额定电流 | 额定转速 | 风量 | 风压 | 噪音 | 重量 | |||
| Listed Model | Rated Voltage | Rated Current A | Rated Speed | Air Floe | Air Pressure | Noise Level | Weight | |||
| VDC | 12 | 24 | 48 | 60 | RPM | CFM | mmH₂O | dBA | g | |
| QD12038H | 12/24/48/60 | 1.30 | 0.60 | 0.35 | 0.25 | 3800 | 160.0 | 14.3 | 51 | 270 |
| QD12038M | 0.60 | 0.30 | 0.18 | 0.12 | 3000 | 120.6 | 7.5 | 43 | ||
| QD12038L | 0.30 | 0.18 | 0.10 | 0.06 | 2000 | 80.5 | 4.3 | 34 | ||
